The thoroughly proven machines, equipped with high-quality, durable precision tooling, ensure cost-effective operations and excellent reliability. The in-line system is controlled from a touch screen, which is easy to navigate and allows for quick setup of nail parameters. Once the nail dimensions are set, production can take place unmanned, and only limited staff is required to carry out changeovers and maintenance.
KYA Fasteners now launching brand new High Speed Nail Making machine(760 nails per minute). Here we are sharing you the first look of KYA-X90.
KYA Fasteners’s High speed nail making machine is a combination of market demand and any of the advance technology available. It’s designed and developed to be highly automated electromechanical integrated product. This nail making machine have wide usages, simple operation and reliable run. High speed nails making machine KYA-X90 New Design generation, a revolutionary progress in nail making industry. This equipment has the advantages of convenient operation, stable quality, low consumption and low unit cost, low manpower etc.
High speed nail making machine is the new designed nail machine type for making wire nails, D type nails, paper nails, double head nails and clout nails. Speed 600-800 pcs/min, Model X50, X90 and X130,X150. The maintenance of the high speed nail making machine is the daily work that must be done to keep the machine tool in good condition, prolong the service life and improve the production efficiency. After the machine tool runs for a certain period of time, wear occurs due to the parts that are in contact with each other. Its working performance is gradually affected. At this time, the machine tool should be checked and adjusted regularly. Regular inspections should generally be carried out by operators under the guidance of maintenance personnel.
This video shows an wire nail making machine of the high-capacity nail + series with smart. KYA's nail manufacturing machine are indeed the more efficient in the market. Featuring the smart software platform, the nail is brought to the next level of high-performance automatic steel nail making machinery by unique patent,two time heading,double-dies and double-punches structure technology to enable extensive quality control and fast trouble shooting.
The automation control system means double capacity, better nail quality, less space requirements, increased user-friendliness, fewer operators and the possibility of unmanned production.one worker can operate 6-8 sets machines at same time.
Manufactured using a high-grade raw material, our products are appreciated for their high efficiency, stupendous performance, and reliability.
Nail Making Machine Detail
Nail Making Machine Features
Nail Cutter Holder Adopts Pendulum Structure
1. Shorter stroke and lower mechanical wear. 2. High precision, nail cutters work without touch with longer service life. 3. One set of cutters' cutting times up to 10 million times.
Unique Patent, Double-dies and Double-punches Structure
1. Bigger nail heads can be easily gotten 2. Nail heads are always very round and in the center. 3. Nail head without knock marks, consistent and good looking 4. Uniform thickness and diameter of the nail head.
Feeding and Anti-backing Structure
1. High-precision feeding unit. Length difference can be controlled within 0.3 mm 2. With unique wire feeding and anti-backing structure, the nail scraps can be completely separated from the nail shank to ensure quality.
KYA Nail Machine
● Through disruptive transformation of the traditional nail-making process and the use of automated controls, the problems of inconsistent length, off-center nail head, varying nail head sizes, pointed or bent nails, and limited nail quality due to structural limitations of traditional nail-making machines and the skill level of nail-making workers have been completely resolved. High rates of defective products and wastage have also been addressed. ● This product features disruptive design and innovation in the overall nail-making process, nail head formation, and mechanical design, effectively addressing the various drawbacks of traditional nail-making machines. It significantly reduces production costs, helping businesses to reduce nail-making labor by 50-70% and coiling labor by 35-45%. It greatly improves product quality, reduces production costs, and enhances the core competitiveness of the factory. ● The smart software platform comes with an intuitive touch screen interface, which displays steel nail information, quality, production and performance status. The interface is easy to navigate and allows for quick setup unique user levels.
Nail Length (mm):25-60mm Nail Diameter (mm):1.8-2.8mm Motor (kw):5.5kw+1.5kw Speed (pcs/min):760pcs/min Diemensions (mm):1500x950x1300mm Weight:2800kg
X90 High Speed Nail Making Machine
Nail Length (mm):38-90mm Nail Diameter (mm):2.0-3.5mm Motor (kw):5.5kw+1.5kw Speed (pcs/min):760pcs/min Diemensions (mm):1900x1200x1150mm Weight:3100kg
X130 High Speed Nail Making Machine
Nail Length (mm):70-130mm Nail Diameter (mm):2.5-4.5mm Motor (kw):7.5kw+2.2kw Speed (pcs/min):500-650pcs/min Diemensions (mm):2200x1300x1300mm Weight:3950kg
X150 High Speed Nail Making Machine
Nail Length (mm):70-150mm Nail Diameter (mm):2.5-5.0mm Motor (kw):11kw+2.2kw Speed (pcs/min):500-650pcs/min Diemensions (mm):2400x1400x1400mm Weight:4350kg
We can send engineers to your company for machine installation. The round trip flight tickets, local transportation, local accommodation should be paid by your company. Engineer service charge is US$100/day.
If only adjust the length of nails and keep the same wire diameter. 3-5 minutes is enough. If the nail diameter also need to be changed, then around 20 minutes will be needed for adjusting the feeding unit and gripping dies.
